Embedded ARM Motherboard RK3566 Quad-core 64-bit Cortex-A55 Processor ANDROID 11/Linux Ubuntu OS For POS Machine

1 piece sample is supported.
MOQ
$40-$60
Price
Embedded ARM Motherboard RK3566 Quad-core 64-bit Cortex-A55 Processor ANDROID 11/Linux Ubuntu OS For POS Machine
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Product Name: Embedded ARM Motherboard RK3566
Power Input: DC12V-28V Input
Audio Output: Stereo, Support The Social Sound Effects
OS: ANDROID 11/Linux Ubuntu
PCB Size: 125mm*90mm
Dual Screen Display: Support For EDP, MIPI
RTC: Support
Highlight:

RK3566 ARM motherboard for POS

,

Quad-core Cortex-A55 embedded board

,

Android 11 Linux Ubuntu ARM board
Basic Infomation
Place of Origin: China
Brand Name: JEWELLED
Model Number: JLD-P02
Payment & Shipping Terms
Packaging Details: 1pc/bubble bag, proper qty in a carton
Delivery Time: 3-5 working days for sample
Payment Terms: TT /Paypal
Supply Ability: 100K/month
Product Description
RK3566 Embedded ARM Motherboard for POS Systems
High-performance quad-core 64-bit Cortex-A55 processor motherboard supporting Android 11 and Linux Ubuntu operating systems, designed specifically for commercial POS machine applications.
Hardware Specifications
CPU RK3566 Quad-core 64-bit Cortex-A55 processor, maximum frequency 1.8GHz
GPU ARM G52 2EE support OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1
NPU 1TOPS
Memory 2G/4G/8G DDR4 optional
EMMC 16G-128G optional
Display Support LVDS, EDP, MIPI
Audio Output Stereo, support Dolby sound effect
Audio Port 3.5mm headphone jack, 2P2.0 microphone interface, 4P2.0 speaker interface
Ethernet 10/100M
Wi-Fi 2.4G/5G WiFi BT
OS Android 11/Ubuntu 20.04/Debian 10
TP I2C /USB interface TP
Memory Card Type TF-CARD
USB Interface Built-in USB 2.0 sockets (4 pcs), external USB 2.0 (2 pcs) 3.0 (1 pce) OTG (1 pce)
Serial Port 5 in total, optional types, TTL (1-5 pcs), RS232 (0-4 pcs)
RTC Support power-off clock memory, automatic power on and off
Camera USB camera
PCB Size 125mm*90mm*1.6mm
Power Supply DC12V-24V input
Temperature -20° - 80℃
Embedded ARM Motherboard RK3566 Quad-core 64-bit Cortex-A55 Processor ANDROID 11/Linux Ubuntu OS For POS Machine 0 Embedded ARM Motherboard RK3566 Quad-core 64-bit Cortex-A55 Processor ANDROID 11/Linux Ubuntu OS For POS Machine 1 Embedded ARM Motherboard RK3566 Quad-core 64-bit Cortex-A55 Processor ANDROID 11/Linux Ubuntu OS For POS Machine 2
Product Overview
This embedded ARM motherboard features the Rockchip RK3566 quad-core 64-bit Cortex-A55 processor, delivering robust performance with excellent power consumption optimization. Supporting both Android 11 and Linux Ubuntu operating systems, it provides a cost-effective hardware solution for commercial terminal devices including POS machines.
Audio & Video Capabilities
The motherboard supports flexible vertical and horizontal video image adjustment to accommodate various POS machine display layouts and diverse scenario requirements. Audio output utilizes stereo architecture with Dolby Audio technology compatibility, delivering clear, full audio for voice announcements and customer guidance functions.
Network Connectivity
Equipped with Gigabit Ethernet for high-speed wired transmission, ensuring stable, low-latency transaction data and device command interaction. The integrated 2.4G/5G dual-band WiFi module enables wireless networking, eliminating cabling limitations for easy deployment in commercial environments and flexible device networking with remote management capabilities.
Application Benefits
  • High-performance computing for demanding commercial applications
  • Comprehensive audio and video interface support
  • Reliable network transmission performance
  • Hardware design meeting stringent commercial terminal requirements
  • Ideal core hardware for POS machine intelligent upgrades and enhanced user experience
