Home /Products/Embedded ARM Board/Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02

Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02

1 piece sample is supported.
MOQ
$45-$80
Price
Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02
Features Gallery Product Description Ratings & Review Request A Quote
Features
Specifications
Product Name: Industrial RK3588 Embedded ARM Board JLD-I02
NPU: 6 TOPS
PCB Size: 170mm*170mm
OS: ANDROID11/Linux Ubuntu
Power Supply Mode:: DC12V Input
Serial Port: 5 In Total, Optional Types，TTL（1-5pcs）、RS232（0-4pcs）、RS485（0-2pcs）
Audio Output: Stereo, Support Dolby Sound Effect
4G/5G: Support 4G/5G Network
Highlight:

RK3588 ARM motherboard with NPU

,

Industrial ARM board with Mali-G610 GPU

,

Embedded ARM board with 6TOPS performance
Basic Infomation
Brand Name: JEWELLED
Model Number: JLD-I02
Payment & Shipping Terms
Packaging Details: 1pc/bubble bag, proper qty in a carton
Delivery Time: 3-5 working days for sample
Payment Terms: T/T Paypal
Supply Ability: 100K/month
Product Description
Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard
High-performance industrial-grade embedded ARM motherboard with 6TOPS NPU and ARM Mali-G610 MC4 GPU (Model: JLD-I02)
Product Overview
The JLD-I02 is a high-performance industrial-grade embedded ARM motherboard based on Rockchip RK3588 SoC. Designed for industrial automation, edge computing, AI vision, and intelligent terminals, this board features high computing power, exceptional reliability, rich interfaces, and long-term stable operation.
Key Specifications
  • DDR4 Memory: Available in 2GB/4GB/8GB options to meet multitasking and large model operation requirements
  • Storage: eMMC available in 16GB-128GB options with TF card expansion support for industrial data storage
  • Ethernet: 1×10/100/1000M adaptive Ethernet port for stable industrial network transmission
  • Wireless: Integrated 2.4G/5G dual-band WiFi + Bluetooth for wireless networking and peripheral connectivity
Advantages of Embedded ARM Board
  • Industrial-Grade Stability: Wide temperature and voltage design with strong anti-interference capability for long-term stable operation in industrial environments
  • Strong AI Computing Power: 6 TOPS NPU efficiently processes image recognition, data inference, and other AI tasks to enhance terminal intelligence
  • Excellent Display Compatibility: Full range of display interfaces suitable for industrial screens, industrial computers, and intelligent display terminals
  • Flexible System Adaptation: Android 11 with multi-system support for convenient secondary development and application deployment
Typical Applications
  • Industrial control terminals and edge computing gateways
  • Intelligent self-service equipment (retail, medical, government affairs)
  • HD video surveillance and multi-screen display terminals
  • Face recognition and AI image recognition equipment
Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02 0 Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02 1 Embedded ARM Board Industrial RK3588 2.8GHz Arm Motherboard With 6TOPS NPU And ARM Mali-G610 MC4 GPU JLD-I02 2
Technical Specifications
ComponentSpecification
CPURK3588 octa-core (4×Cortex-A76 + 4×Cortex-A55) with maximum frequency of 2.8GHz
GPUARM Mali-G610 MC4 supporting OpenGL ES 1.1/2.0/3.1/3.2, Vulkan 1.1,1.2, OpenCL 1.1,1.2,2.0
NPU6 TOPS neural processing unit
Memory2G/4G/8G DDR4 optional
EMMC16G-128G optional
DisplaySupports LVDS (dual 8), EDP, MIPI, HDMI, VGA
Ethernet10/100/1000M
Wi-Fi2.4G/5G WiFi with Bluetooth
Operating SystemAndroid 12 / Linux Ubuntu
Memory CardTF-CARD
USB InterfaceBuilt-in USB 2.0 sockets (5 pcs), external USB 2.0 (2 pcs), external 3.0 HOST/OTG (1 pce)
Serial Port5 total ports with optional types: TTL (1-5pcs), RS232 (0-4pcs), RS485 (0-2pcs)
RTCSupports power-off clock memory with automatic power on/off
CameraUSB camera compatible
PCB Size170mm × 170mm
Power SupplyDC 12V input
Temperature Range-20°C to 80°C
Frequently Asked Questions
What is the brand name of this ARM Android Board product?
The brand name is JEWELLED.
What is the model number of this ARM Android Board product?
The model number is JLD-I02.
Where is this ARM Android Board product manufactured?
This product is manufactured in China.
What are the packaging details for this ARM Android Board product?
Packaging includes 1 piece per bubble bag, with proper quantity in a carton.
