RK3566 Embedded ARM Board
Advanced quad-core 64-bit Cortex-A55 ARM motherboard designed for professional applications including advertising displays, digital signage, self-service terminals, and industrial control systems.
Product Overview
Model A08 embedded ARM motherboard from Shenzhen JLD Technology Co., Ltd. features the powerful Rockchip RK3566 processor, delivering exceptional visual performance and robust AI computing capabilities. Supports comprehensive OEM/ODM customization services.
Key Features
- Multiple display interfaces: LVDS, MIPI, EDP with I2C touch panel support
- Comprehensive connectivity: USB, HDMI, COM ports, headphone jack
- Advanced networking: Ethernet, dual-band WiFi (2.4G & 5G), Bluetooth
- Enhanced EMI/EMC protection for industrial environments
- Gigabit Ethernet for high-speed data transfer
Product Interface Photos
Technical Specifications
| CPU |
RK3568 up to 2.0GHz |
| GPU |
ARM G52 2EE |
| NPU |
1TOPS AI processing |
| Memory |
2G/4G/8G DDR4 optional |
| EMMC Storage |
16G-128G optional |
| Display Interfaces |
LVDS, EDP, MIPI, HDMI |
| Audio |
Stereo with Dolby sound effects, 3.5mm headphone jack, microphone and speaker interfaces |
| Networking |
10/100M/1000M Ethernet, 2.4G/5G WiFi, Bluetooth |
| Operating Systems |
Android 11, Ubuntu 20.04, Debian 10 |
| USB Ports |
4x USB 2.0 internal, 1x USB 3.0 HOST external, 1x OTG external |
| Serial Ports |
4 total (TTL, RS232, RS485 options) |
| PCB Dimensions |
140mm × 91mm × 1.6mm |
| Power Supply |
DC 12V 3A input |
| Operating Temperature |
-20°C to 80°C |
Applications
Outdoor self-service terminals, energy-efficient touch screens, payment station kiosks, self-service payment terminals, POS systems, and various self-service kiosk applications.
Product Certification
Warranty & Support
Quality Assurance
All products undergo strict quality control checks before packaging and are carefully prepared for shipping.
Warranty Terms
Comprehensive 1-year warranty with full maintenance coverage during the warranty period.
After-Sales Service
Extended 1-3 year warranty options available. Immediate technical support provided. Your trusted digital signage solution provider.
